2 Parking Lock
⇒ “2.1 Parking Lock Cover, Removing and Installing”, page 201
⇒ “2.2 Parking Lock, Removing and Installing”, page 203
2.1 Parking Lock Cover, Removing and In‐
stalling
Special tools and workshop equipment required
♦ Pry Lever - 80-200-
Removing
• The transmission is installed.
• The selector lever is in »P«.
– Remove the air filter housing:
♦ Gasoline engine. Refer to ⇒ Rep. Gr. 24 ; Air Filter; Overview
- Air Filter Housing .
♦ TDI engine. Refer to ⇒ Rep. Gr. 23 ; Diesel Direct Injection
System; Overview - Air Filter .
– Remove the battery and the battery tray -arrows-. Refer to ⇒
Electrical Equipment; Rep. Gr. 27 ; Battery; Battery, Remov‐
ing and Installing .
– Remove the lock washer -1- from the selector lever cable.
Always replace the circlip on the selector lever cable.
– Remove the selector lever cable -2- from the ball head on the
selector lever using, for example, a Pry Lever - 80-200- .
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤ , Jetta 2011 ➤
7-Speed Dual Clutch Transmission 0AM - Edition 09.2015
2. Parking Lock 201
