6
MODEL
SPECIFICATION
VOLTCRAFT 632FG
30MHz OSCILLOSCOPE + FUNCTION GENERATOR
Sweep Time
0.2μSec ∼ 0.5 Sec/DIV, 20 steps in 1-2-5 sequence.
Sweep Time Accuracy
±3%.
Vernier Sweep Time
Control
≤1/2.5 of panel-indicated value.
Sweep Magnification 10 times (maximum sweep time 100nSec/DIV).
×10 MAG Sweep Time
Accuracy
±5%, (20nSec∼50nSec are uncalibrated).
Linearity
±3%, ×10 MAG:±5% (20ns and 50ns are uncalibrated).
HORIZIONAL
AXIS
Position shift caused by
×10 MAG
Within 2 div. at CRT screen center.
Sensitivity Same as vertical axis (X-axis: CH1 input signal; Y-axis:CH2 input signal.).
Frequency Bandwidth DC to at least 500kHz.
X-Y Phase Difference
≤3
0
at DC ∼50kHz.
X-Y MODE
Sensitivity 5 Vpp (Positive-going signal decreases intensity).
Frequency Bandwidth
DC ∼ 2MHz.
Input resistance
Approx. 47kΩ.
Maximum Input Voltage
30V (DC+AC peak, AC frequency≤1kHz).
Waveform Positive-going Square wave.
Z AXIS
Frequency Approx. 1kHz.
Duty Ratio Within 48:52.
Output Voltage
2 Vpp ±2%.
CALIBRATION
VOLTAGE
Output Impedance
Approx. 1kΩ.
Type 6-inch rectangular type, internal graticule.
Phosphor P31.
Acceleration Voltage Approx. 2kV.
Effective Screen Size 8 × 10 DIV (1 DIV = 10mm (0.39in)).
Graticule
Internal.
CRT
Trace Rotation Provided.
2. FUNCTION GENERATOR
Output Function Range
0.1Hz ~ 1MHz (7 steps).
Output Waveform
Sine Wave, Square Wave Triangle Wave.
Frequency Variable Range
10:1 or more.
Output Impedance
50Ω ± 10%.
Output Voltage
Over 20Vpp (open circuit) continuous conversion.
DC offset possible over ± 6V when opened.
Sine wave Distortion & Jitter
1% Max.(10Hz ∼ 20kHz), (Specification applied from Max. to 1/10 level)
Square wave Unsymmetry
±3% or less (in 1kHz maximum).
Square wave Rise/Fall Time
50Ω output: 120nS or less.
3.GENERAL
Power Source
AC115V, 230V ± 15% selectable, 50Hz or 60Hz.
Power Consumption
Approx. 45VA, 40W(max.)
Operation Environment
Indoor use
Altitude up to 2000 m
Ambient temperature :
To satisfy specifications :10° to 35℃(50° to 95° F)
Maximum operating ranges: 0° to 40℃(32 °to 104° F)
Relative humidity: 85% RH(max.) non condensing
Installation Category II
Pollution degree 2
Storage Temperature & Humidity
-10° to 70℃, 70%RH(maximum).
Accessories
Power cord × 1
Instruction manual × 1
Probes × 2
GTL-101 × 1
Dimensions
310 (W) × 150 (H) × 455 (D) mm.
Weight
Approx.8kgs (17.6lbs).
