VOLTCRAFT CC-8 - 8 Operating Elements

20
8. Operating elements
1
2
3
5
6
7
4
8
1 MODE button
2 LCD Display
3 SLOT button
4 Status indicator
-Green: 9 V battery not connected or fully charged.
-Red: 9 V battery connected and charging.
5 charging slot
6 9 V block battery bay
7 Spring-loaded battery holder
8 Power input: IN:DC12V
