31
Technical Data
PSP 12010 PSP 1405 PSP 1803
Operating voltage 230 V~ / 50 Hz (+/- 15%)
Power consumption max. 300 VA
Output voltage 0 - 20 V/DC 0 - 40 V/DC 0 - 80 V/DC
Output current 0 - 10 A 0 -5 A 0 -2.5 A
Output power max. 200 VA
Residual amplitude max. 10 mVrms (rms = effective) max. 22 mVrms
Control response at
Change of mains supply 10 mV / ≤ 5 mA 10 mV / ≤ 5 mA 15 mV / ≤ 8 mA
+/- 10 %:
Control response at
25 mV / ≤ 10 mA 35 mV / ≤ 20 mA 25 mV / ≤ 10 mA
Change of load 0~100 %:
Interface RS-232, 9-pole D-SUB socket
Protection class 1
Mains connection Low-power device installation plug, IEC C14
Mains fuse Fine fuse, slow-trigger, 3.15A / 250 V
Dimensions (W x H x D) 255 x 110 x 305 (mm)
Weight approx. 2.5 kg
Operating temperature +5°C to +40°C
Rel. air humidity max. 85%, non-condensing
