VOLTCRAFT SL-300 - Specification

3
z FAST & SLOW response
z Analog AC/DC outputs for connection to
frequency analyzer or X-Y shaft recorder
3. SPECIFICATION
Standard applied: IEC61672 -1 CLASS2
Accuracy: +1.4dB
Frequency range: 31.5HZ ~ 8KHZ
Dynamic range: 50dB
Level ranges: LO30dB~80dB
Med50dB~100dB
Hi80dB~130dB
Auto30dB~130dB
Frequency weighting: A/C
Time weighting: FAST ( 125ms ), SLOW (
1s )
Microphone: 1/2 inch electret condenser
microphone
Display: 4 digits LCD display with a
resolution of 0.1dB
Display Update: 2 times/sec.
MAX hold: Hold the Maximum reading
MIN hold: Hold the Minimum reading
HOLD: Hold the readings
Alarm function: “OVER”is when input is
more than upper limit of range.
“UNDER”is when input is less than upper limit
of range.
Analog output : AC/DC outputs from
