46
Operating mode Measuring range Accuracy Resolution:
AC Volt 4 V +/-(1% + 4 dgt) 0,001 V
40 V +/-(1% + 4 dgt) 0.01 V
400 V +/-(1% + 4 dgt) 0,1 V
750 V +/-(1.5% + 4 dgt) 1 V
Overload protection 1000 V, input resistance: 10 MW
True relative value measuring from 10 to 100% of the measuring range
Alternate current frequency: 45 Hz to 1 KHz
Crest factor max. 3
DC Ampere 400 µA +/-(0,5%+10) 0,01 µA
4000 µA +/-(0,5%+10) 0,1 µA
40 mA +/-(0,5%+10) 0,001 mA
400 mA +/-(0,8%+10) 0,01mA
10 A +/-(1,5%+20) 0,001 A
Overload protection µA/mA 0.5A 250 V swift tripping fuse
10 A 10 A 250 V swift tripping fuse
Measuring duration in the 10 A range: 0 to </=5 A permanent measuring,
> 5A max. 10 sec. with 15 min. break
AC Ampere 400 µA +/-(1,2%+4) 0,1 µA
4000 µA +/-(1,2%+4) 1 µA
40 mA +/-(1,2%+4) 0,01 mA
400 mA +/-(1,2%+4) 0,1mA
10 A +/-(2,0%+3) 0,01 A
Overload protection µA/mA 0.5A 250 V swift tripping fuse
10 A 10 A 250 V swift tripping fuse
Measuring duration in the 10 A range: 0 to </=5 A permanent measuring,
> 5A max. 10 sec. with 15 min. break
True relative value measuring from 10 to 100% of the measuring range
Alternate current frequency: 45 Hz to 1 KHz
Crest factor max. 3
Resistance 400 Ω +/-(0.8% + 10 dgt) 0,01 Ω
4 kΩ +/-(0.5% + 10 dgt) 0.0001 kΩ
40 kΩ +/-(0.5% + 10 dgt) 0,001 kΩ
400 kΩ +/-(0.5% + 10 dgt) 0,01 kΩ
4 kΩ +/-(0.5% + 10 dgt) 0.0001 MΩ
40 MΩ +/-(1.5% + 20 dgt) 0.001 MΩ
Overload protection 1000 V
Continuity tester: acoustic signal with resistances of <50 Ω, test voltage: -1,2V
Diode test Test voltage max. 2.8 V, test voltage max. 1 mA
31
Delivery Scope
Multimeter
Block battery 9V
K-type thermal sensor (up to max. 230°C)
Multi-purpose plug for the K-type thermal sensor
Safety measuring cables red and black
Crocodile clamp
Spare fuse 0.5 A 250 V swift tripping 5x20 mm
Spare fuse 10 A 250 V swift tripping 5x20 mm
Operating instructions
Handling and Commissioning
Display and Symbols
HOLD stands for data hold, the measuring value is held (e.g. for logging) until
you press the "HOLD" button again or turn the multimeter off.
stands for relative value measuring
Auto range stands for "Automatic measuring range selection"
OL stands for overload = the measuring range was exceeded
Battery change symbol; change batteries immediately in order to pre-
vent measuring errors!
Symbol for diode test
Symbol for the acoustic continuity test
TRUE RMS Indicator for the real relative value measuring in the AC measuring range
AC = switchover value for voltage and current
DC = direct value for voltage and current
mV = millivolt (exp.–3)
V = Volt (unit of electric voltage)
A = Ampere (unit of electric current)
mA = milliampere (exp.–3)
µA = microampere (exp.-6)
Hz = Hertz (frequency unit)
kHz = Kilohertz (exp.3)
MHz = Megahertz (exp.6)
Ω = Ohm (unit of electric resistance)
kΩ = Kiloohm (exp.3)
MΩ = Megaohm (exp.6)
