Emergency Shifting, Drive
If a fault occurs which prevents the drive from being
operated (shifted) with the control lever, it is possible
to shift manually, using the description below.
WARNING!
In emergency shifting, the unit is locked in forwards
operation. Please note that the drive can not then be
disengaged with
the control lever. Forward motion can
only be cut off by stopping the engine with the ignition
key or stop button..
Manual drive engagement
1 Stop the engine and take the starter key out of the
starter switch.
2 Pull out the split pin (1) and lift the adapter (2) from
the pin (3).
3 Place a screwdriver or similar tool in the adapter
(2) hole and move the control wire horizontally.
In Case of Emergency
47702599 12-2011 65
