Assembly
1 Apply water-resistant grease, P/N 828250 (alt.
21347121) to the splines and threads on both pro-
peller shafts.
2
Install the forward propeller until it bottoms. Attach
the propeller nut with a cranking clockwise motion
until it bottoms. Adjust the position with a reversed
crank until the holes for the screws are lining.
3 Mount the six socket cap screws. Torque 24-28 Nm
(17.7–20.7 ft.lb.).
4 Install the forward propeller until it bottoms. Attach
the propeller nut with a cranking clockwise motion
until it bottoms. Adjust the position with a reversed
crank until the holes for the screws are lining.
5 Mount the six socket cap screws. Torque 24-28 Nm
(17.7–20.7 ft.lb.).
6 Push the spinner into place by hand. Install the
center screw with Volvo Penta locking fluid
1161053 alternative Loctite 242. Pull the center
screw, torque 24–28 Nm (17.7–20.7 ft.lb.).
Loctite 242
24-28 Nm
P0011229
Maintenance
47702096 05-2011 107
