17
TAMD62A
Design and function
1 Air filter
2 By-pass valve (directs air flow through aftercooler)
3 Filter for crankcase breather
4 Aftercooler
5 Heat exchanger
6 Expansion tank
7 Sea water pump
8 Lubrication oil filter (alt. location at left-hand rear
of engine as extra equipment)
9 Flexible engine mountings (extra equipment)
10 Sump
11 Dipstick
12 Start motor
13 Reverse gear, MPM IRM 220A-1
14 Dipstick, reverse gear
234 5
1
7
14 13 12 11 10 9 8
6
