Volvo Penta TAMD72A - Page 22

20
Design and function
TAMD71B
1 Junction box with circuit breakers
2 Coolant filler cap
3 Fuel filter
4 Oil filler cap
5 Injection pump
6 Stop solenoid
7 Turbocharger
8 Oil cooler, reverse gear
9 Reverse gear, TD MG507A
10 Dipstick (alternative location)
11 Oil cooler, engine
12 Smoke limiter
13 Circulation pump
14 Alternator
13456 7
8
12 11 10 9
2
14
13
