19
11
Design and function
TAMD71A
1 Turbocharger
2 Air filter
3 Relay for electric starting heater
4 By-pass valve (directs air flow through aftercooler)
5 Expansion tank
6 Coolant filler cap
7 Lubrication oil filter
8 Sea water pump
9 Heat exchanger
10 Dipstick
11 Aftercooler
12 Start motor
13 Dipstick, reverse gear, TD MG507
14 Oil pump
1 Junction box with circuit breakers
2 Coolant filler cap
3 Fuel filter
4 Oil filler cap (also at front edge of engine)
5 Injection pump
6 Stop solenoid
12 3 4 56 7
9
12
10
8
7 Turbocharger
8 Oil cooler, reverse gear
9 Reverse gear, TD MG507
10 Oil cooler, engine
11 Smoke limiter
12 Circulation pump
123 4 6
7
9
10
1221314
8
11
5
