1996 Volvo 850
Used for measuring shorter distances. The last digit indicates 1/10 mile/kilometer. A black number on a white background =
original speedometer. A red number on a white background = replacement speedometer.
9 Tachometer
Reads thousands of engine rpm. Engine should not be operated in red range. The highest permitted constant engine speed is
6,300 rpm (turbo: 6,200 rpm, B 5252 S: 6,000 rpm).
pg. 1:3 Indicator and warning lights
1 Turn signal, left
2 Turn signal , right
3 (Not in use)
4 Low washer fluid level
If the lamp glows continuously when the engine is running, there is only about 1/2 - 1 US qt. remaining in the washer fluid
reservoir.
5 Low fuel level
When the lamp glows, only about 1.8 US gals. (8 liters) of fuel remain
6 Rear fog light
7 High beams
8 (Not in use)
9 Bulb failure warning sensor
10 (Not in use)
11 (Not in use)
12 SRS
13 Generator not charging
14 Low engine oil pressure
15 Brake warning light
16 Parking brake applied
17 ABS-system
18 Ambient temperature warning light* (certain models)
(see pp. 1:11 or 1:14 for more information)
19 Transmission mode "W", or gear positions 3 or L engaged (automatic transmissions)
20 Low coolant level
file:///K|/ownersdocs/1996/1996_850/96850_101.htm (4 of 7)12/30/2006 9:58:55 AM

Volvo 850 Specifications

Torque Specifications

ABS Sensor Torque	7 ft. lbs. (10 N.m)
Bearing Cap Torque	18 ft. lbs. (25 N.m)
Lug Nuts Torque	81 ft. lbs. (110 N.m)
Suspension Arm Nuts Torque	13 ft. lbs. (18 N.m)
Suspension Arm To Anti-Roll Bar Torque	37 ft. lbs. (50 N.m)
Suspension Arm To Anti-Roll Bar Center Nut Torque	80 ft. lbs. (120 N.m)
