09 Maintenance and service
Replacing bulbs
09
``
211
on or the remote control key inserted into the
ignition switch.
Dipped beam
G020255
Removing the cover and bulb
1. Remove the entire lamp housing.
2. Bend aside the catches and remove the
cover.
3. Release the spring clip securing the bulb.
First, press it to the left to release it, then
out and down.
4. Pull out the bulb.
5. Refit the lamp housing.
G007339
Fitting a new bulb
1. Fit the new bulb. It can only fit in one posi-
tion.
2. Press the spring clip in/up and then slightly
to the right in order to snap it into position.
3. Press the connector back on.
4. Refit the plastic cover.
5. Refit the lamp housing.
Main beam
G007338
1. Remove the entire lamp housing.
2. Left-hand headlamp:
turn the bulb holder anticlockwise.
Right-hand headlamp:
turn the bulb holder clockwise.
3. Withdraw the bulb holder and change the
bulb.
4. Refit the bulb holder. It can only be refitted
in one position.
5. Refit the lamp housing.
