09 Maintenance and service
Replacing bulbs
09
``
213
Front fog lamps
G021046
1. Switch off all lights and turn the remote
control key to position 0.
2. Remove the panel from around the lamp
housing.
3. Remove the two Torx screws securing the
lamp housing and take out the lamp hous-
ing.
4. Unplug the connector from the bulb.
5. Turn the bulb anticlockwise and pull it out.
6. Fit the new bulb and turn it clockwise.
7. Plug in the connector to the bulb.
8. Secure the lamp housing with the screws
and press the panel back into place.
Removing the bulb holder
G020963
All bulbs in the rear lamp cluster can be
changed from inside the cargo area.
±
Switch off all lights and turn the remote
control key to position 0.
NOTE
If the error message remains after a faulty
bulb has been replaced then we recom-
mend that you visit an authorised Volvo
workshop.
Location of the bulbs in the rear light
cluster
G020964
Bulb holder.
Brake light
Position/parking lamps
Rear fog lamp (one side)
Direction indicators
Reversing lamp
