Vonets VAP11G-300 Quick Setting Guide

VONETS WiFi Bridge/Repeater
5
2. The application configuration of Repeater + bridge (The application configuration method
of repeater & bridge is basically the same).
1) Open Browser, input configured page: http://vonets.cfg (or IP: 192.168.254.254), then press
Enter;
2) Enter User name and Password in login page (both are “admin”), click “Login” button to enter
configured page;
3)“Scan Hotspots”, choose the source hotspots, click “Next”;

Vonets VAP11G-300 Specifications

General

Wi-Fi Standard	802.11b/g/n
Frequency	2.4GHz
Max Data Rate	300Mbps
Weight	30g
Storage Temperature	-20°C to 70°C
Antenna	Built-in
Operating Mode	AP, Repeater
Ethernet Port	10/100Mbps
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Port	RJ45
