Vox JamVOX - JamVOX Monitor; Front Panel

En-5
JamVOX installation/setup guide
JamVOX Monitor
TheJamVOXMonitorisa2‐in/2‐outUSBaudiointerfaceandpoweredmonitorwithtwo3‐
inchfull‐rangespeakers.
Itcanalsobeusedasanau
diointerfaceforanysoftwarethatsupportsCoreAudioorASIO.
Front and rear panels
Youmustturndownthevolumeofyourequipmentbeforeyouconnectanything.If
youneglecttotaketh
isprecaution,youriskdamagingyourspeakersystemandother
equipment,orcausingmalfunctions.
Front panel
1. GUITAR IN jack
Connectyourguitarhere.
2. MIC IN jack
Connectyourdynamicmichere.Themiccanbeusedsimultaneouslywiththeguitar.
Onlyadynamicmiccanbeconnected;condensermicsthatrequireapowersupply
cannotbeconnected.
3. MIC INPUT LEVEL knob
Adjuststheinputlevelofthemic.
Do not connect theJamVOXMonitor to your computer before
installing the JamVOX Driver and Software.
Mic
Headphone
Guitar
1
2
3
4
5
6
7
