En-6
4. OUTPUT LEVEL knob
AdjuststheoutputleveloftherearpanelLINEOUTPUTjacks.
IftheJamVOXmonitor’svolumeisinsufficient,youcanconnectitsLINEOUTPUT
jacktoyouraud
iosystem.
5. PHONES jack
Connectyourheadphoneshere.
6. MONITOR LEVEL knob
Adjuststhevolumeoftheinternalspeakersandtheheadphones.
7. POWER ON indicator
ThiswilllightupwhentheJamVOXMonitorisconnectedtoyourcompu terviaUSB,and
thepowerison.
Rear panel
1. USB connector
UsetheincludedUSBcabletoconnectthistotheUSBconnectorofyourcomputer.
2. EXPRESSION PEDAL jack
ConnectanoptionalKorgEXP‐2footcontrollerhere.
3. FOOT SWITCH connector
ConnectanoptionalVOXVFS2footswitchhere.
4. LINE OUTPUT L/R jacks
Connectyouraudioplaybacksystemhere.
5. LINE INPUT L/R jacks
Hereyoucaninputaline‐levelaudiosignal.
1
2
3
4
5
AUX IN
OUTPUT
Audio system etc.
Korg EXP-2
Synthesizer, Audio system etc.
VOX VFS-2
Computer
