Voyager VOM74WP - Product Specifications; Lcd Panel Specifications

14
Size/Type 7” inch (DIAGONAL) TFT LCD
Brightness 400 cd/m
2
Contrast o 500 (Typ)
View Angle 9 o’clock
70゜(typ)
3 o’clock
70゜(typ)
12 o’clock
50゜(typ)
6 o’clock
70゜(typ)
Backlight Type LED
Backlight Life 20,000 hrs. (min)
VOM74WP
PRODUCT SPECIFICATIONS
LCD PANEL SPECIFICATIONS
 on Temperature Range : -20°C ~ +70°C
 Storage Temperature Range : -20°C ~ +70°C
 Max Humidity : 90%

on Voltage : 12 / 24 VDC
 Current Draw (typical) : Max 30W
 Signal System : NTSC or PAL (selectable)
 Video Aspect
o : 16:9
Input Level : 1Vp-p 75Ω
 Audio Input Level : Max 0.2W – 150mV
 Product Weight : 2.2 lbs. / 1kg
 Product Dimensions : Monitor Only Dimensions :
7.7 W X 5.2 H X 1.2 D inches
Flange Dimensions
9.5 W X 6.4 H X 2 D inches
