10
Wall Mounting
The Wall Mount brackets are designed for use on standard wall mount plates
only. Wall mounting is optional.
1. Plug the AC adapters into electrical outlets. Then plug the DC connector of
the Base power adapter to the connector jack at the bottom of the Base Unit.
2. Connect the telephone line cord to the jack at the bottom of the Base Unit,
and the other end to the wall jack.
3. Line up the tabs on the wall mount adapters with the holes at the bottom of the
Base Unit/back of the Handset Charger. Snap the wall mount bracket firmly
in place.
4. Mount the Base Unit/Handset Charger on the wall. Position the Base Unit/
Handset Charger so that the mounting studs will fit into the holes on the wall
mount bracket. Slide Base Unit/Handset Charger down on the mounting
studs until it locks into place.
Getting Started
To Next Page
