27
2. Push the Adjustment Handle as illustrated below. If you cannot see
the whole screw head, continue to turn the handle counterclockwise
until you see the whole screw head exposed.
3. Pull out the Adjustment Handle as illustrated.
4. Attach the Head Tube Clamp onto the Head Tube of the bicycle.
Note: It is recommended to mount the camera on the Head Tube of
the bicycle instead of the Handle Bar as illustrated.
5. Replace and tighten the Adjustment Handle by turning it clockwise
to x the position of the Bicycle Mount.
6. Align the tripod screw hole on the Kidizoom
®
Action Cam 180 to the
screw of the Bicycle Mount. Tighten the screw on the Bicycle Mount
clockwise to afx the Kidizoom
®
Action Cam 180 to the mount.
Handle Bar
Head Tube
Cross Bar
