CHAPTER 5
Specifications
TL2.5 Line Stage
Vacuum Tube Complement 2x12AU7, 2x12AT7
T.H.D. 20 Hz - 20 KHz 0.01%
Signal to Noise Ratio 109 dB
Maximum Output Voltage 60 Volts
Gain 20 dB
Input Impedance 100K ohms
Channel Separation 75 dB @ 1 KHz
Power Consumption 150 Watts
Primary Mains Fuse Rating 1A Slo Blo Ceramic (120Volt AC)
.41 A Slo Blo Ceramic (240 Volt AC)
Dimensions 19” wide x 15” deep x 4” high
Weight 25 lbs
TL2.5 Phono Stage
MM MC
Tube Complement 2x12AX7 2x12AX7, 1x12AX7 JJ
Gain 36.5 dB 58.0dB
Signal to Noise Ratio 85 dB 70 dB
TL2.5 Preamplifier Owner’s Manual
VTL
23
