User Manual Visionpro
®
C Series Display Cube
- -
18
Input/Output Ports of CP30DSC Main Control Board
1）Master Desktop Signal Input Port
Connector Type
DVI-D
Signal Format
TMDS
Dot Clock Frequency
25-330MHz
Horizontal Frequency
31KHz-135KHz
Vertical Frequency
24Hz/30Hz/60Hz/120Hz
Resolution
640x480-4096x2160
Color Depth
24bit
2）Slave Desktop Signal Input Port
Connector Type
DVI-D
Signal Format
TMDS
Dot Clock Frequency
25-330MHz
Horizontal Frequency
31KHz-135KHz
Vertical Frequency
24Hz/30Hz/60Hz/120Hz
Resolution
640x480-4096x2160
Color Depth
24bit
3）Signal Loop-in Port
Connector Type
DisplayPort
Signal Format
SERDES
Dot Clock Frequency
27-330MHz
Horizontal Frequency
31KHz-135KHz
Vertical Frequency
23Hz-121Hz
Resolution
640x480-4096x2160
Color Depth
24bit
4）Signal Loop-out Port
Connector Type
DisplayPort
Signal Format
SERDES
Dot Clock Frequency
27-330MHz
Horizontal Frequency
31KHz-135KHz
Vertical Frequency
23Hz-121Hz
Resolution
640x480-4096x2160
Color Depth
24bit
