User Manual Visionpro
®
C Series Display Cube
- -
21
 Specifications of CP30SCIP Main Control Board
DVI Output Port
Connector Type
DVI-D
Signal Format
TMDS
Dot Clock Frequency
25MHz-165MHz
Horizontal Frequency
35KHz-75KHz
Vertical Frequency
50Hz/60Hz
Resolution
640 × 480-1920×1200
Color Depth
24bit
Control Mode
I
2
C, SCL Frequency<100KHz
Input/ Output Ports of CP30SCIP Main Control Board
1）Desktop Signal Input Port
Digital
Connector Type
DVI-D
Signal Format
TMDS
Dot Clock Frequency
27-165MHz
Horizontal Frequency
31KHz-100KHz
Vertical Frequency
23Hz-121Hz
Resolution
640×480-1920×1200
Color Depth
24bit
2）Ethernet Port
Connector Type
RJ45×2
Port Type
Standard 100M/10M Self-adaptive Ethernet port
3）Sync Signal Input/Output Port
Connector Type
BNC×2
Sync Signal Frequency
50～60HZ
Sync Signal Amplitude
3.0V~～3.6Vpp
