Note:
（1）7-SEG LED Indicator
The 7-SEG LED indicator is controlled through 3 I/O ports. Different display content
indicates different system status. Details are shown in the following table.
Content
System Status
Content
System Status
0
Interface box powered up,
loading program started
0.
Error loading program
1
Application initialization
1.
Error during application initialization
2
IP configuration (static IP or
dynamic IP)
2.
IP configuration failure
3
Interface box started, main
control board powered up
3.
Error starting interface
4
Downloading FPGA program
of main control board
4.
Error downloading FPGA program of
main control board
5
Configuration of FPGA
parameters of main control
board
5.
Error configuring FPGA parameters of
main control board
6
Engine powered on
6.
Error starting engine
7
Waiting for the completion of
engine initialization
7.
Engine initialization error
8
Configuring engine
8.
Engine configuration failure
9
Engine detection
9.
Display failure
E
E.
There are two situations in which E is
displayed: 1. An error is detected, but
this error is not serious enough to
trigger the protection mode. For the
moment, this only includes the DVI
disconnection error. 2. It is displayed
during the 1-minute waiting time before
entering the protection mode.
.
Flashing: engine is shutting
down
.
Standby
Normal operation
