 Specifications of E-CP30SKD04 Signal Processing Board
SDI Signal Input Port
SDI
Connector Type
BNCx2
Signal Format
SDI
Resolution
480i, 576i., 720p, 1080i, 1080p
Vertical Frequency
23.98Hz~60Hz
Signal Amplitude
0.8Vpp
HDMI Signal Input Port
Digital
Connector Type
HDMI
Signal Format
TMDS
Dot Clock Frequency
25~300MHz
Horizontal Frequency
31KHz-100KHz
Vertical Frequency
24~60Hz
Resolution
640×480~4096×2160
Color Depth
24bit
DP Signal Input Port
Digital
Connector Type
DisplayPort
Signal Format
micro-packet
Dot Clock Frequency
25~300MHz
Horizontal Frequency
31KHz-100KHz
Vertical Frequency
24Hz~60Hz
Resolution
640×480~4096×2160
Color Depth
24bit
RGB Signal Input Port
Digital
Connector Type
DVI-D × 2
Signal Format
TMDS
Dot Clock Frequency
27~330MHz
Horizontal Frequency
31KHz~100KHz
Vertical Frequency
23Hz-121Hz
Resolution
640×480~4096×2160
Color Depth
24bit
