Signal Loop-in/Loop-out Port
Signal Loop1-in Port
Connector Type
DisplayPort
Signal Format
SERDES
Dot Clock Frequency
27~330MHz
Horizontal Frequency
31KHz~100KHz
Vertical Frequency
23Hz-121Hz
Resolution
640×480~4096×2160
Color Depth
24bit
Signal Loop1-out Port
Connector Type
DisplayPort
Signal Format
SERDES
Dot Clock Frequency
27~330MHz
Horizontal Frequency
31KHz~100KHz
Vertical Frequency
23Hz~121Hz
Resolution
640×480~4096×2160
Color Depth
24bit
Signal Loop2-in Port
Connector Type
DisplayPort
Signal Format
TMDS
Dot Clock Frequency
27-165MHz
Horizontal Frequency
31KHz~135KHz
Vertical Frequency
23Hz-121Hz
Resolution
640×480~1920×1200
Color Depth
24bit
Signal Loop2-out Port
Connector Type
DisplayPort
Signal Format
TMDS
Dot Clock Frequency
27~165MHz
Horizontal Frequency
31KHz~135KHz
Vertical Frequency
23Hz~121Hz
Resolution
640×480~1920×1200
Color Depth
24bit
Note:
（1）SDI1 signal input port and SDI2 signal input port are backups for each other.
（2）DRGB1 signal input port and DRGB2 signal port are backups for each other.
