Genlock Sync Signal Input Port/ Vertical Sync Signal Output Port
Genlock
Connector Type
BNC×2
Sync Signal Frequency
50～60Hz
Sync Signal Input Amplitude
3.0V~～5.5Vpp
Sync Signal Input Amplitude(Analog
black burst/HD tri-level sync)
0.3Vpp~1.2Vpp
Sync Signal Output Amplitude
3.0V~～3.6Vpp
HDMI Signal Input Port
Digital
Connector Type
HDMI
Signal Format
TMDS
Dot Clock Frequency
27MHz-165MHz
Horizontal Frequency
31KHz-100KHz
Vertical Frequency
50~60Hz
Resolution
480i, 480p, 576i, 576P, 720P, 1080i,1080p
Color Depth
24bit
Signal Loop Port
Signal Loop1-in Port
Connector Type
Dual-DVI
Signal Format
TMDS
Dot Clock Frequency
27-165MHz
Horizontal Frequency
31KHz-100KHz
Vertical Frequency
23Hz-121Hz
Resolution
640×480~1920×1200
Color Depth
24bit
Signal Loop1-out Port
Connector Type
Dual-DVI
Signal Format
TMDS
Dot Clock Frequency
27~165MHz
Horizontal Frequency
31KHz~100KHz
Vertical Frequency
23Hz~121Hz
Resolution
640×480~1920×1200
Color Depth
24bit
