1.2.2 Interface Parameters
 Signal input channel
DRGB port
Digital
Connector type
DVI-D
Signal format
TMDS
Dot clock range
27MHz ~148.5MHz
Horizontal scanning frequency range
36.25KHz~67.5KHz
Vertical scanning frequency range
50Hz~60Hz
Resolution range
640×480~1920×1080
Color depth
24bit
 Control port
Serial port control and control loop-in
Connector type:
DB9F
Serial port type:
RS232
Data format:
8 data bits, 1 stop bit, no check bit
Baud rate:
9600
Input signal amplitude:
±3V~±15V
Output signal amplitude:
>±4V
Control loop-out
Connector type:
DB9F
Serial port type:
RS232
Data format:
8 data bits, 1 stop bit, no check bit
Baud rate:
9600
Input signal amplitude:
±3V~±15V
