6
• Install the system on level ground and in a well- lit area,
no less than 2 m (6 ft) from any structure or obstruction –
such as a fence, garage, house, overhanging branches,
laundry lines, or electrical wires.
• Ensure that your chosen surface allows the system to be
firmly embedded with the included Anchor Kit or with
strong bolts.
• Preference installing the system on a surface with
impact-attenuating properties – such as grass. A fall
onto a hard surface can result in serious injury or
death to the equipment user.
• Check that you have all parts required for assembly.
• Lock nuts and bolts securely.
• Children must not use the equipment until properly
installed.
3.0. Pre-assembly
3.1. Size Referance
467cm
300cm
475cm
390cm
475cm
490cm
Medium Large Extra Large
3.2. Tips & Tricks
Difficulty inserting joiners to frame tubes can be resolved by
inverting the and tapping the joiner inside against a scrap
piece of wood
3.2.1. Joiner Fitting
To align the joiner holes with the holes in the frame tube,
take the large 8mm Allen key and insert it into the top hole
in the joiner tube then twist until the holes align. If further
alignment is required, remove the Allen key and place it
through the holes in the joiner and the tube. Use the Allen
key to leverage the holes into alignment.
To Next Page
