7
2x Medium Climbing Bar 2x Short Climbing Bar
2x Long Climbing Bar
3x Climbing Bar (Straight)
3.3. Parts Reference
DO NOT REMOVE PARTS FROM CARTONS UNTIL REQUIRED, OR MIX CARTON CONTENTS.
BOX A
LARGE:
3.2.2. Uneven Ground
If assembling the Quest on uneven ground adjusting the flip rails will reduce rocking. If the Quest still seems unsteady, loosen
the feet and move them down slightly.
A4.1
A4.2
A4.3
A4.4
8x Frame Bolts & Nuts 18x Locking bolts & Washers
2x 2-hole Climbing Rail
2x 3-hole Climbing Rail
2x Curved Climbing Rail
A3
A1
A2
