Vuly Quest Large - Page 9

9
2x 4-Way Joiner
2x Large T-Joiner
2x Feet
2x Upper Outer Leg Tube 2x Lower Outer Leg Tube2x Joiner Tube
4x Joiner Tube
BOX G
LARGE :
BOX F
LARGE:
2x Large Top Rail4x Upper Frame Tube
6x T-Joiner
F1
F2 F3
F4 F5
G1 G2
G3
G4 G5
7x Accessory Joiner
F6
4x Frame Bolts & Nuts
8x Frame Bolts & Nuts
1x Long Outer Shade Tube 1x Short Outer Shade Tube
1x Short Shade Tube
1x Long Shade Tube
1x Shade Cover
5x Tension Hook
SHADE COVER
LARGE:
5x i-Bolt
L1
L2 L3
L4
40x Anchors
