F-003
10
1
2
05 MOUNTING OPTIONS INSTALLING THE MOUNTING BRACKET
1. Remove 1 set screw from mounting bracket and set aside
for use in Finishing the Installation.
2. Pass supply wires through mounting bracket and secure to
outlet box. Your outlet box should come with pre-
attached screws for your hanger bracket. Install your
hanger bracket as shown.
Standard Ceiling Slope Ceiling
Caution: Remember to disconnect
the power at the circuit breaker.
CAUTION: To prevent electrical shock, ensure electricity has been
turned o at the circuit breaker before beginning.
Figures 1 and 2 are examples of different ways to mount the
outlet box. Use A hardware if needed to mount your outlet box.
