WAC Lighting CLEAN - Package Contents

9F-003
NOTE: ** denotes nish code of fan
1
9
5
3
8
4
13
2
7
10
11
12
Canopy Ring
RPL-CAN-RND-
**
Adapter Plate
Luminaire Cover
RPL-F003-COVER-
**
Coupling
Cover
Hardware Bag
RPL-003-PARTS
Canopy
RPL-CAN-CYL-**
Motor Housing
Fan Blade
RPL-F003-52-
**
Remote Control
RC20-WT
PACKAGE CONTENTS 04
Downrod
Assembly
Mounting
Bracket
RPL-HGR-ASM-
**
PC Shade
(F-003L version)
RPL-F003-GLA
Luminaire Module
(F-003L version)
F3IN-120V-R1-30
Receiver
F-R3-003-052
14
A: Junction Box
Pan Head Phillips Screw (2)
Flat Washers (2)
Pan Head Phillips Screws (2)
B: Blades
Blade Screws (10)
C: Safety Cable
Flat Washer (1)
Spring Washer (1)
Wood Screws(1)
D: Wire Connectors (8)
E: Optional Light Kit
(F-003L version)
5/32 * 22mm Pan Head
Screws (4)
