WAC Lighting CLEAN - Installing the Optional Wall Control; Multi-Location Wall Control Wiring

F-003
16
1. Install the wall control using the wiring diagram above.
2. Individually pair each of the wall controls with the fan receiver using the pairing instruction.
08 INSTALLING THE OPTIONAL WALL CONTROL
11
Wall Control 1 Wall Control 2 Wall Control 3
