ATTACHING THE FAN BLADES
06
1. Insert blades in slots, aligning with motor assembly holes.
2. Secure blades with blade attachment screws & washers
as shown.
For Blade installation, use
B parts:
3/16"x13mm Head Screws (10)
Φ5x14x1.5mm Paper Washer (10)
