NOTE: ** denotes nish code of fan
3
1
2
7
6
4
5
8
Receiver
F-R3-036-044
F-R3-037-052
Hardware Bag
RPL-HUG-PARTS
9
A: Junction Box
#10 x 38mm Pan Head Phillip Screws (2)
Ø5 x 14 x 1mm Flat Washer (2)
3/16" Star Washer (2)
B: Blade Arm and Blade
3/16" x 13" Blade Screws (10)
5 x 15 x 1.5mm Paper Washers (10)
C: Safety Cable
Φ6.5x19x2mm Flat Washer (1pc)
3/16"(Φ5.2x8.4x1.0mm) Spring Washer (1)
#10x76mm Pan Head Phillip Wood Screws(1)
D: Wire Connectors (8)
Fan Blade
RPL-F036-BD-44-**
RPL-F037-BD-52-**
LED Module
F4IN-120V-R1-30
Glass Shade Cap
RPL-HUG-GLA
Motor Housing
Adapter Plate
Mounting Bracket
RPL-HUG-HGR
PACKAGE CONTENTS 04
Remote Control
RC20-WT
