3-66 BA 901/1101 en – Edition 2.1 * 91101b340.fm
Operation
If the material is hard to penetrate:
☞ Proceed as for loading loose material, but in addition:
☞ Slightly tilt the bucket in and out
Ending loading:
☞ Tilt in the bucket C
☞ Reduce engine speed
☞ Reverse out of the material A
☞ Raise the bucket to transport position B
Removing material/digging in soft soil
If foundations or walls are undermined – danger of collapse
Accident hazard!
☞ Never undermine foundations or walls!
☞ Place the bucket horizontally on the ground B
☞ Set the digging angle 1
Fig. 76: Loading if the material is hard to penetrate
Fig. 77: Tilting in the bucket
C
Fig. 78: Reversing out of the material
B
A
Fig. 79: Lowering the loader unit to the ground
B
1
Fig. 80: Adjusting the digging angle
1
