5-6 BA 901/1101 en – Edition 2.1 * 91101b510.fm
Maintenance
Adding engine oil
Too much or incorrect engine oil can cause engine damage! For this reason:
☞ Do not add engine oil above the MAX mark of oil dipstick 90/A
☞ Use only the specified engine oil
Use a suitable container to collect the engine oil as it drains and dispose of it in an
environmentally friendly manner!
Adding engine oil
☞ Proceed as follows:
• Clean the area around oil filler cap B with a lint-free cloth
• Open filler cap B
• Raise oil dipstick A slightly to allow any trapped air to escape
• Add engine oil
• Wait about 3 minutes until all the oil has run into the oil sump
• Check the oil level – see Checking the oil level on page 5-5
• Add oil if necessary and check the oil level again
• Close filler cap B
• Push oil dipstick A back in as far as possible
• Completely remove all oil spills from the engine
Fig. 90: Oil dipstick and oil filler cap
A
B
OIL
