BA 901/1101 en – Edition 2.1 * 91101b110.fm 1-3
Introduction
1.3 Brief description
The model 901 and 1101 compact loaders are self-propelled work machines.
Get informed on and follow the legal regulations of your country.
This machine is a versatile and powerful helper for moving earth, gravel and debris on con-
struction sites and elsewhere. A wide range of attachments accounts for the numerous
applications of the machine. See chapter 1.4 Fields of application, attachments for further
applications.
The main components of the machine are:
• ROPS tested cabin
• FOPS 1 tested cabin
• FOPS 2 tested cabin (option)
• Models 901s and 1101c: water-cooled turbocharged Deutz diesel engine
• Model 901sp is available as an option with features differing from model 901s as
follows:
• Powerflow hydraulic system with increased oil flow
• Model 1101cp is available as an option with features differing from model 1101c as
follows:
• Powerflow hydraulic system with increased oil flow
• Sturdy steel sheet chassis, rubber-mounted engine
• Axial piston motor with reduction gear
• Hydraulic parking brake
The machine can be equipped with the “Telematic” option (for transmitting oper-
ating data, location, etc. via satellite).
Traveling drive
The diesel engine permanently drives two axial-piston variable displacement pumps
whose oil flow is sent to the axial piston motors on the left and right.
Operating hydraulics
The diesel engine also drives the joint gear pump for the operating hydraulics. The oil flow
of this pump depends on the diesel engine speed only.
Cooling system
The indicator lights on the instrument panel of the machine ensure constant monitoring of
the engine and hydraulic oil temperature, as well as of the coolant temperature and level.
