Technical Data
TD00738GB.fm 17
3. Technical Data
*
Length depends on shank
BH 24
Item no.
0008937,
0008993,
0008994
0008995,
0610082,
0610083
0008996
with remonte
cut-off
Length x width x height (without tool) [mm]
900 - 950 x 450 x 340*
Operating weight (mass) without tool [kg]
25
Shaft for breaking tools
ø 27x80 / 28x152 / 28x160
Percussion rate [min
-1
]
1250 1300
Drive motor
Two-cycle gasoline engine
Rated output [kW (HP)]
1,7 (2,3)
Engine speed [rpm]
4250 4400
Special lubricating grease
Retinax LX2 grease
Fuel [Oil mixture-gasolinel]
1:50 (1:100)
Fuel consumption [l/h]
0,9
Tank capacity [l]
2,1
Sound pressure level L
PA at operator's station [dB(A)]
101
Hand-transmitted vibration (in accordance with
EN ISO 5349) [m/s
2
]
64,9
