Technical Data
Machine 16.3
57
[us] | 06/2020 | 5100056974 | AS | Operator’s manual
Type AS30e AS50e
Width [mm] 361 363
Height [mm] 1.046 1.050
Length (Ramming shoe) [mm] 296 340
Width (Ramming shoe) [mm] 150 280
Operating weight [kg] 41,7 71
Lift at ramming shoe [mm] 40 44
Engine type Asynchronous engine Asynchronmotor
Insulation class F F
Rated ouput [kW] 1,300 1,950
Rated torque [Nm] 2,100 3,300
Rated speed [1/min] 4.700 4.350
Recommended battery type BP1000; BP1400 BP1000; BP1400
Special lubricants Gadus S3 V220C 2 SAE 10W30
Relubrication interval [h] 50 250
Oil specifications (Ramming system) _ SAE 10W40
Oil volume (Ramming system) [l] _ 0,700
Protection type IP23 IP23D
Operating temperature range [°C] 0 – +45 0 – +45
Storage temperature range [°C] -30 – +50 -30 – +50
Sound pressure level LpA [dB(A)] 87 91
Sound power level LWa measured [dB(A)] 103 102
Sound power level LWa guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 7,5 7,1
Measurement uncertainty of the total vibration value
ahv [m/s2]
1,0 2,2
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
Type AS60e
Material number 5100052267
Rated current [A] 44,00
Rated voltage [V] 51
Rated ouput [kW] 2,24
Type of current (output) Direct current (DC)
Number of strokes [1/min] 680
Forward travel [m/min] 12,1
Impact force [kN] 17
Length [mm] 610
Width [mm] 363
Height [mm] 1.050
Length (Ramming shoe) [mm] 340
Width (Ramming shoe) [mm] 280
Operating weight [kg] 71
Lift at ramming shoe [mm] 61
16
