TD00575GB
8
TECHNICAL DATA
BPU 3545A
Item no. 0008783 ...
Operating weight
without extension plates (440) kg: 294
with extension plates narrow (500) kg: 308
with extension plates Serial (600) kg: 317
with extension plates wide (760) kg: 336
Power transmission From drive engine directly to exciter unit
via centrifugal clutch and gasoline engine
Exciter
Vibrations min
-1
(Hz): 4150 (69)
Multigrade oil SAE 10W-40
Centrifugal force kN: 35
Drive motor Air-cooled single-cylinder 4-stroke gasoline
engine with recoil starter
Piston displacement cm
3
: 270
Rated power kW: 6,6
at rpm min
-1
: 3600
Operating rpm’s min
-1
: 2600
Oil SAE 10W-40
Fuel gasoline
Fuel consumption l/h: 1,6
Tank capacity l: 6,4
Electrical system Internal ignition cut-off switch
The required sound specifications, called-for by the EC-Machine Regulations per Appendix 1, Paragraph
1.7.4.f, are
- sound pressure level at the operator's location L
pA
= 88 dB(A)
The sound values were determined according to ISO 3744 for the sound power level (L
wA
) and, alternately,
ISO 6081 for the sound pressure level (L
pA
) at the operator's location.
The weighted effective acceleration value, determined according to ISO 8662, Part 1, is 6,4 m/s
2
.
The sound and vibration measurements were carried out and obtained with the machine working on crushed
gravel at nominal engine speed.
