Wacker Neuson BS 50-4 User Manual

BS 50-4 Safety Information
wc_si000117gb.fm 21
Throttle control lever:
Turtle = Idle or Slow
Rabbit = Full or Fast
Fuel valve:
Closed
Open
Engine stop button:
Press to stop engine.
Choke:
0 = Open
l = Closed
This rammer is equipped with a low oil shutoff
switch, it will not allow the engine to operate
unless a sufficient amount of oil is present.
See section Low Oil Shutoff Switch.
Label Meaning

Wacker Neuson BS 50-4 Specifications

General

Engine Manufacturer	Honda
Stroke Height	65 mm
Fuel Type	Gasoline
Centrifugal Force	15 kN
Sound Pressure Level	92 dB(A)
Sound Power Level	105 dB(A)
Height	965 mm
Ramming Shoe Size	280 mm
Tank Capacity	3.1 l
Fuel Tank Capacity	3.1 l
Engine Type	4-cycle, single-cylinder, air-cooled
Percussion Rate	680 blows/min
