BS 50-4 Maintenance
wc_tx000309gb.fm 33
6.5 Shoe Hardware
See Graphic: wc_gr000048
On new machines, or after replacing shoe, check and tighten shoe
hardware (a) after the first 5 hours of operation. Inspect hardware
every week thereafter.
Torque hardware as specified.
6.6 Long-Term Storage
6.6.1 Drain fuel from tank.
6.6.2 Start engine and run until remaining fuel is used.
6.6.3 Remove spark plug. Pour approximately 30 ml (1 oz.) of clean SAE
10W30 engine oil into cylinder through spark plug opening.
6.6.4 Pull starter rope slowly to distribute oil in engine.
6.6.5 Re-install spark plug.
w c _ g r 0 0 0 0 4 8
a
8 6 N m
( 6 3 f t . l b s . )

Other manuals for Wacker Neuson BS 50-4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Wacker Neuson BS 50-4 and is the answer not in the manual?

Wacker Neuson BS 50-4 Specifications

General IconGeneral
Engine ManufacturerHonda
Stroke Height65 mm
Fuel TypeGasoline
Centrifugal Force15 kN
Sound Pressure Level92 dB(A)
Sound Power Level105 dB(A)
Height965 mm
Ramming Shoe Size280 mm
Tank Capacity3.1 l
Fuel Tank Capacity3.1 l
Engine Type4-cycle, single-cylinder, air-cooled
Percussion Rate680 blows/min
