Page #28 background imageLoading...
Page #28 background image
Operation BS 50-4
wc_tx000308gb.fm 26
5.6 Low Oil Shutoff Switch (if equipped)
The low oil shutoff switch is designed to prevent engine damage
caused by an insufficient amount of oil.
When starting the machine:
if the warning light flashes quickly once, this indicates the engine
oil level is acceptable.
if the warning light flashes slowly, the engine will start but shut off
after 10-12 seconds, this indicates that the engine oil level is low.
Add oil to the engine. See Technical Data for oil quantity and
type.
if the warning light stays on continuously, the engine will start and
continue to run but the low oil shutoff switch is not functioning
properly. Check the switch for proper wire connections. If the light
continues to stay on, replace the switch.
if the warning light does not flash quickly once, and the engine
starts and continues to run, the low oil shutoff switch is not
functioning properly. Check the switch for proper wire
connections and grounding. If the light still does not flash when
starting the machine, replace the switch.

Other manuals for Wacker Neuson BS 50-4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Wacker Neuson BS 50-4 and is the answer not in the manual?

Wacker Neuson BS 50-4 Specifications

General IconGeneral
Engine ManufacturerHonda
Stroke Height65 mm
Fuel TypeGasoline
Centrifugal Force15 kN
Sound Pressure Level92 dB(A)
Sound Power Level105 dB(A)
Height965 mm
Ramming Shoe Size280 mm
Tank Capacity3.1 l
Fuel Tank Capacity3.1 l
Engine Type4-cycle, single-cylinder, air-cooled
Percussion Rate680 blows/min
