BS 50-4 Operation
wc_tx000308gb.fm 25
Note: First time use, engines recently serviced, run out of fuel or not
used for long periods of time may need the rope to be pulled more
times to move fuel to the carburetor.
5.4.6 Open choke (b2) on the carburetor as the engine warms up.
Note: A cold engine should be allowed to warm up at the idle position
(c2) for approximately one (1) minute. Failure to open the choke after
the engine attempts to start may cause flooding.
CAUTION: Always open choke (b2) with throttle in idle position (c2).
Opening choke with throttle not in idle position (c2) may result in
rammer motion.
5.5 To Stop
See Graphic: wc_gr001454
5.5.1 Place throttle in the idle position (c2).
5.5.2 Turn engine switch to "OFF" (d).
5.5.3 Close fuel valve (e).
c1
c2
c3
c4
b1
b2
d
a
e

Other manuals for Wacker Neuson BS 50-4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Wacker Neuson BS 50-4 and is the answer not in the manual?

Wacker Neuson BS 50-4 Specifications

General IconGeneral
Engine ManufacturerHonda
Stroke Height65 mm
Fuel TypeGasoline
Centrifugal Force15 kN
Sound Pressure Level92 dB(A)
Sound Power Level105 dB(A)
Height965 mm
Ramming Shoe Size280 mm
Tank Capacity3.1 l
Fuel Tank Capacity3.1 l
Engine Type4-cycle, single-cylinder, air-cooled
Percussion Rate680 blows/min
