Maintenance work
T01127en.fm 62
8.7 Replacing the suction head
The felt filter (13) of the suction head can become clogged during op-
eration. To ensure an unrestricted flow of fuel to the carburetor, the
suction head should be replaced about every 3 months.
Unscrew the fuel tank cap (12), pull the retainer out of the tank open-
ing.
Empty the tank.
To change it, pull the suction head through the tank cap opening using
a wire hook.
Notice: Avoid skin and eye contact with mineral products!
8.8 Replacing the starter rope
Release the four screws (14). Remove the valve housing (15).
Unscrew the two screws (16) and carefully disconnect the air horn (17)
from the valve housing (15). Always proceed in the order
(A-B-C-D).
Remove any leftover rope (18).
