SV00080en.fm 23
Safety information
NOTICE:
It is prohibited to change the direction (a radius of 5 m (16 feet) or less),
apply lateral pressure or tilt the cut-off saw while you are cutting (11)!
4.6.3 Cutting blades must only be used to cut materials they were designed
for. Depending on the material you wish to cut (metal or concrete), you
must select the proper disc type.
4.6.4 The arbor diameter of the cutting blade must precisely fit the shaft. If
the arbor diameter is larger, you must use an intermediate ring as an
adapter.
4.6.5 The cutting blade must be approved for freehand cutting with a
400 mm (16") cutting blade diameter up to 3,850 rpm or 80 m/s
(260 ft./sec), a 350 mm (14") cutting blade diameter up to 4,370 rpm or
80 m/s (260 ft./sec) or a 300 mm (12") cutting blade diameter up to
5,100 rpm or 80 m/s (260 ft./sec). Use only cutting blades that comply
with EN 12413 or EN 13236.
4.6.6 The cutting blade must be completely undamaged (12). Test it by per-
forming a sound test with a piece of wood.
Always tighten the cutting blade to 30 Nm, otherwise you may distort
the cutting blade.
4.6.7 Before starting, the operator must stand at safe distance away from the
cut-off saw.
12
