Guide cart
T00964en.fm 72
9. Guide cart
9.1 Application
The Wacker Neuson guide cart makes it easier to move the cut-off saw
in a straight line. It allows operators to work without fatigue and can be
adjusted based on body height. The cut-off saw can be operated with
the cutting attachment in either the center or outer position.
Fitting the tank with an angular fuel tank filler neck is recommended
when using the guide cart to make refueling easier.
The guide cart is equipped with a water tank and a water sprayer to
bind dust particles together during the cutting process and to cool the
cutting blade.
There are notches in the clamping lever to make it easier to set the cut-
ting depth. One notch equals 10 mm cutting depth.
