Maintenance CT 36 / CT 48
wc_tx000374gb.fm 38
4.10 Adjusting Idle Speed - Honda
See Graphic: wc_gr001122
Remove the drive belt before making any adjustment to the carburetor.
See Belt Replacement. The blades will engage unless the belt is
removed from the machine.
Adjust engine to the no load or idle speed per the Technical Data.
4.10.1 Start the engine and allow it to warm up to normal operating
temperature.
4.10.2 Turn the throttle stop screw (a) in to increase speed, out to decrease
speed. Make sure the throttle lever is touching the stop screw before
measuring rpm.
WARNING
wc_gr001122
a
